GOB LED Modules Product Details
GOB (Glue on Board) LED modules feature an advanced encapsulation technology that coats the PCB and SMD LEDs with a transparent protective layer. This enhances impact resistance, dustproofing, and provides mild waterproofing, making them ideal for indoor applications requiring extra durability, such as museums, retail showrooms, and conference centers. With high contrast and uniform brightness, these modules deliver stunning visuals while resisting scratches and moisture. Available in various fine pixel pitches, they offer seamless installation and reliable performance.
Specification
Model
GOB Module
Available
P1.25-P2.6
Panel Size
320*160mm/250*250mm
Viewing Angle
Ultra-Wide 160°/140°
Contrast Ratio
4000:1
Refresh Rate
3840Hz
/SPECIFICATIONS
Specifications of GOB LED Modules Product Details
GOB (Glue on Board) LED modules feature an advanced encapsulation technology that coats the PCB and SMD LEDs with a transparent protective layer. This enhances impact resistance, dustproofing, and provides mild waterproofing, making them ideal for indoor applications requiring extra durability, such as museums, retail showrooms, and conference centers. With high contrast and uniform brightness, these modules deliver stunning visuals while resisting scratches and moisture. Available in various fine pixel pitches, they offer seamless installation and reliable performance
320x160mm Series GOB LED Screen Panel
Pixel Pitch
LED Type
Module Size（MM）
Module Resolution
Driving Mode
Module Resolution
Module Resolution
P1.25-1010-320x160(GOB)
P1.25mm
SMD1010 (Black LED)
320*160
256*128
1/32
3840
600
P1.53-1010-320x160(GOB)
P1.53mm
SMD1212 (Black LED)
320*160
208*104
1/26
3840
600
P1.86-1515-320x160(GOB)
P1.86mm
SMD1515(Black LED)
320*160
172*86
1/43
3840
600
P2-1515-320x160(GOB)
P2mm
SMD1515(Black LED)
320*160
160*80
1/40
3840
700
P2.5-2020-320x160(GOB)
P2.5mm
SMD2020(Black LED)
320*160
128*64
1/32
1920 / 3840
800
P3.076-2020-320x160(GOB)
P3.076mm
SMD2020(Black LED)
320*160
104*52
1/26
1920 / 3840
800
250x250mm Series GOB LED Display Panel
Pixel Pitch
LED Type
Module Size（MM）
Module Resolution
Driving Mode
Module Resolution
Module Resolution
P1.56-1212-250x250(GOB)
P1.56mm
SMD1212(Black LED
250*250
160*160
1/40
3840
750
P1.95-1515-250x250(GOB)
P1.95mm
SMD1515(Black LED)
250*250
128*128
1/32
3840
800
P2.5-1515-250x250(GOB)
P2.5mm
SMD1515(Black LED)
250*250
100*100
1/25
3840
800
P2.6-1515-250x250(GOB)
P2.6mm
SMD1515(Black LED)
250*250
96*96
1/32
3840
750
/FEATURES
Core Advantages of GOB LED Modules Product Details
GOB LED modules feature a protective glue coating that enhances impact resistance and provides surface waterproofing. This technology delivers superior durability, high contrast, and seamless visuals for indoor applications like museums, retail, and corporate spaces, ensuring reliable performance and stunning image quality.
Impact Resistant
Transparent glue layer absorbs shocks, protecting LEDs from physical damage during handling, installation, or accidental bumps.
Surface Waterproof
Coating provides IP54 protection against splashes and moisture, ideal for humid indoor environments or temporary outdoor use.
Enhanced Contrast
Glue reduces light reflection, delivering deeper blacks and richer colors for exceptional image clarity and vibrancy.
Scratch Resistant
Protective layer shields LEDs from scratches during cleaning or maintenance, maintaining display perfection over time.
Dustproof Protection
Sealed surface prevents dust accumulation, reducing maintenance frequency and ensuring consistent brightness and color.
Wide Viewing Angle
Preserves original SMD viewing characteristics, ensuring uniform image quality from any position without distortion
Installation of GOB LED Modules Product Details
GOB LED modules feature a protective coating that allows safe handling during installation. Standard mounting methods apply while the durable surface resists scratches and impacts. Ideal for indoor high-traffic areas like museums and retail, installation is simple and secure.
Best Price, Front-Service LED Display
Seamless, Front-Service LED Display for Fast Installation & Premium Visual Performance
Magnetic Front Mounting
Strong magnets secure modules to frames, enabling tool-free attachment and quick repositioning. Protective GOB coating prevents damage during repeated handling.
Flush Wall Integration
Modules mount directly onto walls using slim brackets. Hidden cables maintain aesthetics. GOB coating allows safe cleaning without scratching LED surface.
Splash-Proof Edge Sealing
Additional silicone seals between modules enhance moisture resistance. Ideal for humid environments like indoor pools or fountains while maintaining front access.
Supported Installation Methods
- Wall mount
- Recessed
- Suspended
- Rental frame installation
/FEATURES
installation-of-gob-led-modules-product-details
Impact Resistant Surface
Transparent glue coating absorbs shocks and protects LEDs from physical damage during handling, installation, or accidental impacts.
Splash-Proof Protection
Provides IP54 front protection against water splashes and moisture, suitable for humid indoor environments and light exposure.
Enhanced Visual Contrast
Coating reduces light reflection, delivering deeper blacks and more vibrant colors for superior image quality and clarity.
Scratch Resistant Coating
Protective layer shields LED surface from scratches during cleaning or maintenance, ensuring long-term display perfection.
Dustproof Sealing
Sealed surface prevents dust particle accumulation, reducing cleaning frequency and maintaining consistent brightness.
Wide Viewing Angle
Preserves original SMD optical characteristics, ensuring uniform brightness and color accuracy from any viewing position.
GOB LED Modules Product Details Waterproof Certification
GOB LED modules feature a protective glue coating that provides front-side waterproofing while the rear remains unprotected. This design offers splash resistance from the front, making them suitable for indoor environments with occasional moisture exposure, while requiring careful rear installation away from water sources.
Waterproof Rating:Front IP54, Rear Non-waterproof
- Front surface certified IP54 splash-proof
- Protective coating shields against light water exposure
- Rear side must not contact water or moisture
- Suitable for humid indoor environments only
- Edge seals prevent water penetration from front
- Rear requires dry installation conditions
Vibration Resistance Rating of GOB LED Modules Product Details
GOB LED modules feature a protective glue coating that enhances structural integrity and vibration resistance. The encapsulation absorbs shocks and secures components, ensuring stable performance during transportation and in high-vibration environments, preventing pixel damage or display flickering.
- Certified to ISTA transport vibration standards
- GOB coating absorbs shocks and reduces stress
- Reinforced solder joints prevent cracking
- Passes 30-minute simulated vibration testing
- No pixel loosening under continuous vibration
- Maintains image stability during transport
Dustproof Rating of GOB LED Modules Product Details
GOB LED modules utilize a protective glue coating that seals the entire front surface against dust particles. This encapsulation prevents dust accumulation on LEDs and components, ensuring consistent brightness and image clarity in indoor environments while reducing maintenance frequency.
- Certified to IP5X dustproof protection level
- GOB coating fully seals front surface
- Prevents dust penetration between LEDs
- Passes dust chamber testing standards
- No performance degradation in dusty areas
- Easy cleaning with sealed smooth surfac
/Services
Technical Support for GOB LED Modules Product Details
Our LED display specialists are available to provide professional consultation, project guidance, and real-time technical assistance-ensuring every project runs smoothly from planning to operation.
Response Time: Within 24 hours for global customers.
Professional Consultation
Receive expert recommendations on LED display models, specifications, installation methods, and scenario-based solutions.
Project Engineering Support
Receive step-by-step guidance for project design, wiring structure, configuration, and deployment-from planning to on-site implementation.
Real-Time Technical Assistance
Our support team is ready to troubleshoot issues, optimize settings, and ensure your LED display runs smoothly in real environments.
After-Sales Training &Resources
We provide training materials, user manuals, and remote training sessions to help your team easily operate and maintain the system.
